Rockfon® Tropic™ 20mm: Box sizes and weights
| Rockfon code | Type of ceiling | Edge type | Module Size (mm) | Tiles per box | Coverage per box (m2) | Weight (Kg/m2) | Rockfon installation system |
|---|---|---|---|---|---|---|---|
| 178905 | Visible grid | A15 | 600 x 600 x 20 | 24 | 8.64 | 2.4 | T15 A |
| 176951 | Visible grid | A15 | 1200 x 600 x 20 | 12 | 8.64 | 2.4 | T15 A |
| 178905 | Visible grid | A24 | 600 x 600 x 20 | 24 | 8.64 | 2.4 | T24 A |
| 176951 | Visible grid | A24 | 1200 x 600 x 20 | 12 | 8.64 | 2.4 | T24 A |
| 288651 | Semi-concealed grid | E15 | 600 x 600 x 20 | 12 | 4.32 | 2.8 | T15 E |
| 138971 | Semi-concealed grid | E15 | 1200 x 600 x 20 | 12 | 8.64 | 2.8 | T15 E |
| 163223 | Semi-concealed grid | E24 | 600 x 600 x 20 | 12 | 4.32 | 2.8 | T24 E |
| 240218 | Semi-concealed grid | E24 | 120 x 600 x 20 | 12 | 8.64 | 2.8 | T24 E |
